MS-C2966-X12RPE Pro Bullet Zoom 12X,2Mp, AI, Lente Motorizada

  • Bullet de la serie PRO con Inteligencia Artificial. Zoom ótico 12X. AF Motorizado. Sensor 1/2.8"
  • 2MP · AI · 3 en 1 Super WDR Pro · 0.001Lux Ultra Low-light · Mapa de calor · IP67  · IK10 · Smart IR II · Distancia IR de 180 m · Hasta 90 fps · Sensor de luz estelar STARVIS de 1/1,8" · Lente 5.3~64mm · NDAA
  • Análisis de video con IA.
  • Zoom Óptico 12X
  • Conteo de personas
  • Mapa de calor avanzado
  • Última tecnología LED IR
  • Diseño único para una fácil instalación
  • Soporte SIP/VoIP

* Admite PoE; tarjeta SD, hasta 256G; diseño de 3 ejes; Protección contra sobretensiones 4KV,

* Compatible con H.265+/H.265/H.264+/H.264

* Gestión de cables integrada

* Puerto múltiple: E/S de alarma, E/S de audio, DC 12V

* Análisis de contenido de video, conteo de personas, mapa de calor

* Detección de rostros (solo para la serie PC)



Opcional:

* High Frame Rate:  (Serie -T: 2MP@90fps)

* Módulo de calefacción: (Temperatura de trabajo de la cámara: -60℃~60℃)

Conteo de personas

El conteo de personas de alta precisión y en tiempo real basado en el algoritmo de IA, con informes estadísticos para un análisis más detallado, ayuda a tomar decisiones rápidas sobre la gestión de la seguridad y aumenta la eficiencia operativa del negocio.

Camera Name 2MP AI 12X Pro Bullet Plus Network Camera
Image Sensor 1/2.8" Progressive Scan CMOS
Min. Illumination Color: 0.002Lux @F1.2, Color: 0.005Lux @F1.6, B/W: 0Lux with IR on
WDR 120dB Super WDR
Shutter Time 1/100000s∼1s
Day/Night Mode Day/Night/Auto/Customize/Schedule
IR Distance Up to 180m
S/N >55dB
Lens Lens 5.3~64mm, 12X Optical Zoom
Field of View H61°~H5°/D69°~D5°/V36°~V2°
Mount Φ14
Focus Control Auto/Manual
Aperture F1.6~F2.8
Iris Control Auto
Video Max. Image Resolution 1920x1080
Frame Rate 60Hz: 90fps@(1920x1080)(Optional for T Series), 60fps@(1920x1080, 1280x960, 1280x720, 704x576)
50Hz: 90fps@(1920x1080)(Optional for T Series), 50fps@(1920x1080, 1280x960, 1280x720, 704x576)
Secondary Stream 60Hz: 90fps@(704x576)(Optional for T Series), 60fps@(704x576, 640x480, 640x360, 352x288, 320x240)
50Hz: 90fps@(704x576)(Optional for T Series), 50fps@(704x576, 640x480, 640x360, 352x288, 320x240)
Tertiary Stream 60Hz: 30fps@(1280x720, 704x576, 640x480, 640x360, 352x288, 320x240)
50Hz: 25fps@(1280x720, 704x576, 640x480, 640x360, 352x288, 320x240)
Video Compression H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
Video Bit Rate 16Kbps∼16Mbps (CBR/VBR adjustable)
Privacy Masking Up to 24 areas
ROI Up to 8 areas
Image Settings Saturation/Brightness/Contrast/Sharpness
Web Access Support IE/Firefox/Chrome/Safari Browser
Audio Audio Compression G.711/AAC/G.722/G.726
Audio Sampling Rate 8/16/32/44.1/48KHz
Audio Bit Rate 16~256kbps
Two-way Audio Support
Interface Ethernet 1*RJ45 10M/100M Ethernet Port
Audio I/O 1/1
Alarm I/O 1/1
Network Network Storage NAS(Support NFS, SMB/CIFS), ANR
Network Protocols IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, Bonjour, SIP, SNMP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL
Intelligent Analytics Video Analysis Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Object Left, Object Removed
People Counting& Report Count the number of people entering or exiting, up to 4 detection areas for regional people counting
System Storage Support microSD/SDHC/SDXC Card Local Storage, up to 256G
Advanced Function BLC, HLC, 2D DNR, 3D DNR, AWB, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark
SIP/VoIP Support Yes, Voice&Video-over-IP
Event Trigger Motion Detection, Network Disconnection, External Input, Audio Alarm, etc.
Event Action FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc
System Compatibility ONVIF Profile G & Q & S & T, API
General Working Temperature -40℃∼60℃/-60℃∼60℃(Optional for Heater Version)
Working Humidity 0∼90%(Non-condensing)
Power Supply PoE (802.3at) / DC 12V±10%
Power Consumption 7W MAX, 13W MAX (With IR on)
10W Max (With Heater on)
Heater on: below 10℃, Heater off: above 25℃
Surge Protection 4KV
Weather Proof Up to IP67-rated for weather-resistant performance
Housing Vandal-proof IK10-rated metal housing
Dimensions 320mmX134mmX126mm
Weight 1447g
Warranty 3/5 Years
MS-C2966-X12RPE

Ficha técnica

Lentes
5.3~64mm
Distancia IR
180 mts
Estructura
Bullet
Resolución
2Mp 1920x1080

Descargas

Ficha Técnica

Milesight-AI-4X&12X-Pro-Bullet-Plus-IP-NDAA-Datasheet

Descargas (1.5MB)
